What is the difference between P235GH steel and P265GH steel? steel plate

Both P235GH steel and P265GH steel are non-alloy steel pressure vessel plate. As a well-known China manufacturer and exporter of non-Alloy steel plates, we can supply pressure vessel plates with thickness up to 250mm.

Below is the tensile properties difference between P235GH steel and P265GH steel at room temperature.
EN10028 Thickness Tensile properties at room temperature Min. impact energy of Temperature ℃
Grade mm Yield Strength
Mpa≥		 Tensile Strength
Mpa		 Elongation
% ≥		 -20 0 20
P235GH ≤16 235 360～480 24 27 34 40
16＜t≤40 225 360～480
40＜t≤60 215 360～480
60＜t≤100 200 360～480
100＜t≤150 185 350～480
150＜t≤250 170 340～480
P265GH ≤16 265 410～530 22 27 34 40
16＜t≤40 255 410～530
40＜t≤60 245 410～530
60＜t≤100 215 410～530
100＜t≤150 200 400～530
150＜t≤250 185 390～530
If you are looking for pressure vessel plate P235GH steel and P265GH steel sheet price, please feel free to contact us. We will provide high quality P235GH steel and P265GH steel plates with heat treatment and deep processing service like flame cutting, grinding, welding and drilling.
